Cellink Neo 5 4500mAh dashcam battery pack

This Cellink Neo 5 4500mAh is Cellink's entry-level battery pack. It is specially designed to use your dashcam's parking mode without draining your car's battery. The Neo5 has a capacity of 4500mAh and its slim design allows you to neatly conceal it in almost any car.

The Cellink Neo 5 comes with all the necessary accessories to professionally install and integrate it into your vehicle. The Cellink Neo 5 4500mAh is made of durable materials and has a sturdy aluminum housing that can withstand shocks and temperature fluctuations. This Cellink Neo 5 is the universal alternative to the BlackVue Power Magic Ultra Battery B-124E and is made by the same manufacturer.

Hardwire connection

The advanced Cellink Neo 5 4500mAh can be connected directly to a switched fuse or other power point in the car so that it is only charged while driving. After turning off the car's ignition (and thus interrupting the power supply to the Cellink), the Cellink will automatically supply power to the dashcam along with a signal that the parking mode on the dashcam can be activated. This way, you don't have to worry about it anymore.

A special 3-wire output cable is supplied with the Cellink Neo5 to transmit the signal to the dashcam. Connect the 3-wire hardwire kit of your dashcam (which you would normally connect to the fuse box of the car) to this cable.

Please note: To use the parking mode on a dashcam, the hardwire kit of the dashcam must be connected to the 3-wire output of the Cellink. When using the Plug&Play cigarette lighter output, the parking mode will not work on most dashcams and the dashcam will continue to film until the Cellink is empty.

Plug&Play connection

Only with Allcam does the Cellink Neo 5 come standard with a cigarette charger and female cigarette plug so that the power bank can be easily connected and used. Simply plug the included cigarette power input into the car and the cigarette power of the dashcam into the female output of the Cellink Neo 5. Please note that with this connection, the automatic parking mode via the 3-wire connection (parking mode on contact) does not work. Only dashcams with visual automatic parking mode can therefore be used in parking mode with the Cellink Neo 6 Plug&Play method.

Up to 18 hours of power*

The Cellink Neo 5 charges within 30 minutes while driving (with hardwire power supply) and then provides up to 18 hours of power to the dashcam without further draining the car battery. Once the Cellink is empty, the dashcam will switch off and will not drain the car battery any further.

* The operating time can vary greatly depending on the dashcam model. Dashcams with multiple active functions (Cloud, GPS, etc.), higher resolution, or multiple cameras consume more power and the operating time may be reduced to around 6 hours.

Specifications

Capacity: 4500mAh 58kWh

Cigarette lighter input: 12V-17V 6.5A Max

Hardwire power input: 12V-17V 13.5A max

Output: 11V-14.2V 2A Max

Cigarette lighter charging time: 48 minutes

Hardwire charging time: 30 minutes

Operating time: Up to 18 hours (based on 3Wh dashcam)

Weight: 1250 grams

Dimensions: 15.7*13.5*3.9 cm

Cable lengths:

- Hardwire input cable: 3.0m

- Hardwire output cable: 1.8m

- Cigarette input cable: 1.5m

- Cigarette output cable: 0.1m (you can connect the long cigarette power supply of the dashcam to this)
